Basic Info.
| Model NO. | SL-1212 | Origin | China |
| Spindle Number | Double-Spindle | Spindle Layout | Horizontal |
| Controlling Mode | CNC | Feed Mode | Manual |
| Customized | Customized | Certification | CE |
| Color | Customized | Condition | New |
| Applicable Industries | Woodworking Factories,Flooring Industry | After-sales Service | 1 Year |
| Voltage | 380V, 50Hz | Function | Woodworking Machinery |
| Power Type | Electric | Installation Service | on-Site Installation |
|
Transport Package |
Wooden Box/Wrapping Film | Core Components | Engine, Bearing, Gearbox, Motor, etc. |
Packaging & Delivery
| Package Size | Package Gross Weight |
| 1500.00cm * 1500.00cm * 1000.00cm | 2100.000kg |
Product Description
Video
Specification
|
Performance Indicators |
Parameter |
|
Parameter |
1200mm |
|
Y Itinerary |
1200mm |
|
Z Itinerary |
200mm |
|
Platform size |
1200*1200mm |
|
Processing accuracy |
±0.01mm |
|
Repeat positioning accuracy |
±0.01mm |
|
Table top structure |
Vacuum adsorption |
|
X,Y,Z structure |
Ball Screws in Taiwan |
|
spindle power |
7.5KW air-cooled |
|
spindle speed |
0-18000r/min |
|
Operation mode |
Servo |
|
Operating Voltage |
AC380V/50HZ |
|
Run command |
G gode |
|
Operating ststem |
Taiwan imported control system |
|
Motor overload rate |
140% |
|
Net weight |
2000KG |
|
Gross weight |
2100KG |
FAQ
Q1:How long is the warranty period?
A: The free warranty period is one year.
Q2: Is after-sales service provided?
A: For on-site installation and maintenance, the buyer is responsible for providing the air tickets of the technical personnel,Matters related to hotels, etc.
Q3: Why choose our products?
A: We possess strong technological research and development capabilities, advanced production equipment and solid processing technology.
Hot Tags: cnc special shaped flooring slotting machine, China cnc special shaped flooring slotting machine manufacturers, suppliers, factory
