| Max.size of horizontal tenon | 140mm(W)*80mm(H) |
| Max.size of vertical tenon | 80mm(W)*80mm(H) |
| Max. Dia. of round tenon | φ80mm |
| Max. Depth of tenon | 70mm |
| Spindle dia | φ30mm |
| Spindle speed | 8500r/min |
| Spindle motor | 3.0kW |
| Motor of X-axis | 1.0kW |
| Motor of Y-axis | 1.0kW |
| Table tilt angle | 20° |
| Air supply pressure | 0.6MPa |
| Weight | 1000kg |
| Dimension | 215×130×178cm |
For more details, contact us. Here are some samples:
Note: all above pictures and parameters are subject to the real product. We reserve the right to improve the product.
