| Working thickness | 40～70mm |
| Max. working width | 450mm |
| Min. working length | 600mm |
| Feeding speed | 6～24m/min |
| Spindle dia | φ60mm |
| Spindle speed | 4500r/min |
| Upper blade dia | φ160mm |
| Bottom blade dia | φ160mm |
| Total power | 64.75kW |
| Top spindle motor(compression motor) | 30kW |
| Bottom spindle motor | 30kW |
| Feeding motor | 4kW |
| Beam lifting motor | 0.75kW |
| Upper feeding wheel dia | φ140×φ35mm |
| Dust outlet dia | φ140×4个 |
| Table height | 860mm |
| Dimension(L×W×H) | 285×158×162cm |
| Weight | 2800kg |
1. The machine body(frame) is made of cast iron.
2. Equipped with anti-kick back fingers at the feed inlet, for operator safety.
3. Top and bottom spindles as a whole for manual lifting.
4. Feeding speed is controlled by frequency inverter.
5. For more details, please contact us.
Note: all above pictures and parameters are subject to the real product. We reserve the right to improve the product.
